Description
| PARAMETERS | DG MODELS | ||||||
|---|---|---|---|---|---|---|---|
| Genset Prime Rating (kVA) * | 15 | ||||||
| Duty (Standby/ Prime) | Prime | ||||||
| Power Rating @ 100% kWe (in KW) | 12 | ||||||
| No. of Phases | 1 Ph / 3 Ph | ||||||
| Output Voltage (V) | 230 / 415 | ||||||
| Power Factor (lagging) | 0.8 | ||||||
| Current (A) | 65.2/20.9 | ||||||
| Frequency (Hz) & RPM | 50/1500 | ||||||
| Governing Class | G2 | ||||||
| Genset dimensions (L x W x H) in mm | 1875 X 1000 X 1195 | ||||||
| Genset Weight (Kg) Approx. | 765 | ||||||
| Engine Specification | |||||||
| Make | Mahindra | ||||||
| Model | mGreen3235NGC4+ | ||||||
| Power Output# (Kw) | 16.7/23 | ||||||
| Aspiration | NA | ||||||
| No. of cylinders | 3 | ||||||
| Bore x Stroke (mm) | 88.9 X 110 | ||||||
| Displacement (Ltr) | 2.05 | ||||||
| Cooling System | Liquid Cooled | ||||||
| Fuel consumption @ 75% load (kg/hr) ** | 2.4 | ||||||
| Fuel consumption @ 100% load (kg/hr)** | 3.1 | ||||||
| Starting system | 12 V DC Electrical | ||||||
| Air Cleaner | Dry Type | ||||||
| Lube oil specification | Maximile CNG Plus | ||||||
| Total lubrication system capacity | 6.5 | ||||||
| Lube oil consumption @ full load$ | 0.15% of Fuel consumption | ||||||
| Lube oil change period (hrs.) | 500 | ||||||
| Radiator coolant capacity (liter) | 5.5 | ||||||
| Alternator | |||||||
| Make | CG/LS/STAMFORD | ||||||
| Enclosure Type | IP 23 | ||||||
| Voltage regulation | +/- 1% with 4% engine Governing | ||||||
| Class of insulation | H | ||||||
| Maximum Unbalanced Load across Phases | 25% | ||||||
Above specifications are subject to changed without notice due to continuous technical devlopment
* A tolrance of +/- 5% will applicable on declared power values
** Genset Height is without silencer
***A tolrence of +5% shall be applicable on fuel consumption values on account of product to product variation due to engine & +3% of tolarence due to alternator product to product variations
